Product Description:
Polycarbonate corrugated sheets are lightweight, highly durable,
and transparent or translucent sheets with a wavy or ridged
structure, designed for a variety of roofing and cladding
applications. They are made from polycarbonate resin, which
provides exceptional strength and weather resistance. These sheets
are widely used for their excellent balance of toughness,
flexibility, and light transmission.
Key Features of Polycarbonate Corrugated Sheets:
Durability and Impact Resistance: Polycarbonate corrugated sheets are extremely impact-resistant, up
to 200-250 times stronger than glass, and can withstand harsh
weather conditions such as hail, heavy rain, and strong winds. This
makes them ideal for outdoor applications.
Lightweight: These sheets are much lighter than glass or metal, making them
easy to handle, transport, and install without the need for
heavy-duty structural support.
High Light Transmission: Polycarbonate corrugated sheets offer excellent light
transmission, typically ranging from 60% to 90%, depending on
thickness and color. This makes them ideal for applications where
natural light is desired, such as greenhouses, patios, and
skylights.
UV Protection: They come with a co-extruded UV protection layer that blocks
harmful UV radiation, preventing the material from yellowing or
becoming brittle due to prolonged exposure to sunlight. This
extends the life of the sheets in outdoor conditions.
Temperature Resistance: Polycarbonate corrugated sheets can withstand a wide temperature
range, typically from -40°C to 120°C, without becoming deformed or
losing their structural integrity.
Flexibility: The corrugated design allows for a high degree of flexibility,
making the sheets easy to curve and shape to fit different roofing
styles or structures.
Weather Resistance: These sheets are highly resistant to extreme weather conditions,
including snow, rain, UV rays, and even acid rain, making them
suitable for both industrial and residential roofing applications.
Easy Installation: The lightweight and flexible nature of polycarbonate corrugated
sheets makes them easy to cut, drill, and install. They can be
fixed with standard screws and fasteners, reducing labor costs and
installation time.
Specifications of Polycarbonate Corrugated Sheets:
| Specification | Details |
|---|
| Material | Polycarbonate (PC) |
| Thickness | 0.8mm, 1.0mm, 1.2mm, 1.5mm, 2.0mm |
| Width | 760mm, 820mm, 930mm, 1050mm (varies by profile type) |
| Length | 6000mm, 12000mm (custom lengths available) |
| Profile Types | Trapezoidal, Sinusoidal, Wave, Ribbed |
| Corrugation Height | 16mm, 18mm, 32mm (varies by profile) |
| Light Transmission | 60% - 90% (depending on color and thickness) |
| Impact Strength | 200 times stronger than glass |
| UV Protection | Co-extruded UV protection layer on one or both sides |
| Temperature Resistance | -40°C to 120°C |
| Colors | Clear, Opal, Bronze, Green, Blue, Customized |
| Fire Rating | B1 grade (based on DIN 4102), self-extinguishing |
| Weight | 1.2 - 3.5 kg/m² (varies by thickness) |
| Weather Resistance | Resistant to wind, rain, hail, and extreme temperatures |
| Warranty | 10-15 years (varies by product and manufacturer) |
Applications:
Roofing and Cladding: Ideal for residential, commercial, and industrial roofing
applications, including carports, warehouses, and factory roofs.
The corrugated design enhances strength and allows rainwater to
flow off easily.
Greenhouses and Garden Sheds: High light transmission and UV protection make them perfect for
greenhouses, providing a controlled environment for plant growth.
Skylights and Patios: Polycarbonate corrugated sheets are used for skylights and patio
coverings, offering natural lighting with the added benefit of UV
protection.
Industrial Enclosures: Used for covering outdoor areas, walkways, and industrial
facilities where durability and weather resistance are critical.
Customization:
Product Customization Services for Polycarbonate Sheet
Brand Name: TOPPC
Model Number: TOPPC02
Place of Origin: China
Color: Clear, Blue, Opal, Bronze, Green
Impact Resistance: High
Thickness: 1.0mm-15mm
Weather Resistance: Yes
Warranty: Lifetime, 10 Years 100% Virgin PC With Anti-UV Coating
Polycarbonate sheet, Polycarbonate solid sheet
Support and Services:
Our Plastic Polycarbonate Sheets are designed to provide
exceptional performance in a variety of applications. We offer
technical support and services to ensure that our customers have
access to the information they need to make informed decisions
about their projects. Our team of experts can assist with product
selection, installation guidance, and troubleshooting. We are
committed to providing the highest level of customer service and
support to ensure that our customers are satisfied with their
purchase.
Packing and Shipping:
Product Packaging:
The Plastic Polycarbonate Sheet product will be packaged securely
with protective materials to ensure safe transport. Each sheet will
be individually wrapped in a plastic film to prevent scratches and
damage during shipping.
Shipping:
The Plastic Polycarbonate Sheet product will be shipped through a
reliable courier service to ensure timely and secure delivery.
Shipping fees will be calculated based on the destination and
weight of the package. Customers will receive a tracking number
once the package has been dispatched.
