Brand Name : | TOPPC |
Model Number : | TOPPC04 |
Price : | 2.3USD-8.8USD per sqaure meters |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 100000 square meters per Month |
Delivery Time : | 20 days |
10mm Four-Wall Polycarbonate Sheet
A 10mm four-wall polycarbonate sheet is a multi-wall structure made from high-quality polycarbonate resin, featuring four parallel walls and three air spaces between them. This design enhances its insulation and durability while keeping it lightweight. Here’s a detailed description of its features, benefits, and common applications:
The specifications of a 10mm Four-Wall Polycarbonate Sheet:
Specification | Details |
---|---|
Material | High-quality polycarbonate resin |
Structure | Four-wall (three air spaces) |
Thickness | 10mm |
Weight | ~1.7 kg/m² (varies by density) |
Light Transmission | 60-80% (varies based on color and coating) |
UV Protection | Co-extruded UV layer (one or both sides) |
Thermal Insulation | U-value ~2.5 W/m²·K |
Impact Resistance | 200 times stronger than glass, virtually unbreakable |
Working Temperature | -40°C to +120°C |
Colors | Clear, bronze, blue, green, opal, customized colors available |
Standard Width | 2.1m (customizable) |
Length | Up to 12m (customizable) |
Fire Rating | B1 (DIN 4102), optional fire-retardant grades available |
Bending Radius | Minimum ~1750mm (cold bending capability) |
Lifespan | 10+ years with proper installation and maintenance |
Surface Coatings | UV protection, anti-glare, anti-scratch, self-cleaning (optional) |
Pictures of Porduction and Package:
![]() |
